0.8W - 10.5W,
Constant Current LED Driver for 250-700 mA ,
with low ripple,
NFC,
| Model | Vin | lout | Vout | Pout | Power Factor | Current Ripple | Dimension | Certification |
|---|---|---|---|---|---|---|---|---|
| LMC10W700NLR-Z | 220 - 240 V | 250 - 350 mA | 3 - 30 V | 0.8 - 10.5 W | 0.9C | ±5 % | 85 x 40.4 x 22 mm | CE |
| 500 mA | 3 - 21 V | 1.5 - 10.5 W | ||||||
| 700 mA | 3 - 15 V | 2.1 - 10.5 W |
| Datasheet | LMC10W700NLR-Z | |
|---|---|---|
| CB Certificate | NL-84692 | |
| ENEC Certificate | 88-126258 | |
| EU Declaration of conformity | CE-LMC | |
| GB Declaration of conformity | UKCA_LMC10W |
