LWCBC 25W 120-600mA NFC CASAMBI

Electronic

Specification :

1.2 W - 25.2 W LED Driver for 120-600 mA,
In-Track Adaptor,
Integrated CASAMBI Module,
with low ripple,
NFC,

Quantity

Model	Vin	lout	Vout	Pout	Power Factor	Lamp Type	Dimension	Certification
LWCBC25W600NLR	220–240 V	120-450 mA	10 - 54 V	1.2 - 24.3 W	0.4C-0.9C	±5 %	230.5 x 45.9 x 31 mm	CE/UKCA
		500 mA	10 - 50 V	5.0 - 25.0 W
		600 mA	10 - 42 V	6.0 - 25.2 W

DC Output with adjustable constant current from 120 to 600 mA via NFC in 1 mA steps
Integrated CASAMBI Module
CASAMBI Dimming Range : 1-100%
Average service life 50,000 h
Easy and fast output current setting via NFC (via NFC reader or mobile phone) ←
Operating ambient temperature -20°C - +35°C
Ripple current ±5%
Threaded sleeve M10x1 for mounting the luminaire head
Suitable for Class II luminaires
White,Black,Gray
Protection:
1. Short- & open circuit proof
2. Auto. overheat regulation or cut off
3. Overload protection
4. SELV

	Datasheet	LWCBC25W600NLR
	EU Declaration of conformity	CE_LWCBC Series
	GB Declaration of conformity	UKCA_LWCBC
