15.4 - 40.6 W,
Constant Current LED Driver 1100 / 1200 / 1400 mA,
Output Current Adjustable via Dip Switch,
120 - 277 V wide voltage,
| Model | Vin | lout | Vout | Pout | Power Factor | Current Ripple | Dimension | Certification |
|---|---|---|---|---|---|---|---|---|
| LTC40W1400CALR UNI | 120 - 277 V | 1100 mA | 14-36 V | 15.4-39.6 W | 0.7-0.9 C | ±5 % | Built-in 103.5 x 79 x 30 mm Independent 123.0 x 79 x 30 mm |
ENEC/CE/ UKCA |
| 1200 mA | 14-33 V | 16.8-39.6 W | ||||||
| 1400 mA | 14-29 V | 19.4-40.6 W |
| Datasheet | LTC40W1400CALR UNI | |
|---|---|---|
| CB Certificate | NL-81432 | |
| ENEC Certificate | 88-124158 | |
| EU Declaration of conformity | CE_LTC | |
| GB Declaration of conformity | UKCA_LTC |
